3D Extremely Fast Facial Scanning System
2021-03-13
The MH-RDS FaceScan three-dimensional extremely fast facial scanning system can complete a fast three-dimensional scan of the human face in 1.25 milliseconds (equivalent to 1/800 second) to obtain the three-dimensional shape data of the face. The system realizes three-dimensional scanning of the human face by projecting a white light speckle pattern that is harmless to the human body to the face, and obtains three-dimensional geometric coordinate data and color texture data of the human body at the same time. The scanning accuracy is 0.1mm. The core technology of the system's core algorithm, multi-camera high-precision calibration, and 3D reconstruction has completely independent intellectual property rights. The calculation data does not need to be spliced, and the data accuracy is high. It supports the output of multiple 3D data formats such as asc, ply, stl, and obj. Compared with the laser body scanning system, it is safe and harmless to the human body, especially to the human eye. The subject can keep his eyes open during the whole scanning process, which can be widely used in cosmetic surgery, medical orthopedics and animation production and more.
Technical Advantages
1) Extremely fast scanning: complete image data acquisition within 1.25 milliseconds, avoiding errors caused by human body shaking;
2) Core technology: the principle of speckle projection, using a flash to project a harmless white speckle texture on the human face, and black hair can be collected;
3) High-precision model: the scanning accuracy is 0.1mm, and the three-dimensional geometric and color data of the face are obtained;
4) Synchronous control of multiple probes: automatic registration, fusion and packaging of point cloud data;
5) Easy to operate: high-precision intelligent modeling, without manual stitching;
6) Safe and comfortable: The light source used is ordinary white light, which is harmless to the human body;
7) Customizable functional modules ( Quotation is negotiable )
a. Support multiple measurement modular combinations to achieve three-dimensional scanning of the human head, upper body, and whole body;
b. Support dynamic facial 3D acquisition, the acquisition frequency is (1-70hz) optional;
c. Support the selection of SLR cameras to provide high-resolution texture effects.
System Parameter Configuration
|
Model#
|
MH-RDS FaceScan
|
|
Camera Pixel
|
4 x 2.3 MegaPixels (1920 x 1200)
|
|
Color Camera Pixel
|
2 x 5 MegaPixels (2448 x 2048)
|
|
Number of Measuring Heads
|
2
|
|
Measuring Range
|
500mm×500mm×400mm
|
|
Dot Density
|
500 Dots/cm²
|
|
Measurement Accuracy
|
0.1mm
|
|
Scan Time
|
1.25 ms
|
|
Punctuation Board
|
400*400
|
|
LCD Screen Size
|
9 Inch
|
|
Fill Light
|
LED
|
|
Product Measurement
|
1.5m×0.8m×1.2m
|
|
Equipment Weight
|
35kg
|
