| InSb 640×512 (15㎛) cooled thermal detector |
Engineer Manager Name: Jacky
WhatsApp/ Wechat: 0086-187 9245 6795
Email: mh_elec@126.com or jacky@mh-elec.com
-
Array Format : 640×512
-
Pixel pitch : 15㎛
-
Material : InSb(Indium Antimonide)
-
Wavelength : 3~5 ㎛ (Midwave Infrared)
-
NETD : below 0.02℃
-
Operability : Over 99.5% (Typical. over 99.7%)
-
No. of channel : .1 or 4 channel
-
Readout mode : ITR or IWR
-
Cooling time: within 6 minutes (0.5W stirling cooler)
-
Standard: MIL-STD-810
Application
-
Thermal observation device
-
Gunner Primary Sight in Tank and armoured vehicle
-
Day and night observation device
Overview of Product
Cooled IR Detector(640×512, 15㎛) is developed for next-generation weapon
systems. VGA format IR Detector has 4 times higher resolution and 1/4 pixel size
than QVGA detector (MWIR 320×256, 30㎛). It enables high-resolution image with
same optical systems for QVGA detectors.
Introduction
Cooled IR Detector(640×512, 15㎛) has NETD of below 0.02℃, cooling time of 6
minutes and suitable for high-end thermal imaging equipments. InSb (Indium
Antimonide) is used to get excellent, uniform and stable image qualities.
