MH-S63 Most Effective Electronic Sniper Detection System



Pls click or email to


mh_elec@126.comor jacky@mh-elec.com


The MH-S63 Sniper Detector detects snipers and other forward observers before they fire a shot.

Sniper detection systems are acoustic and help operators respond to a threat after it has already inflicted damage, the Optics Detector functions on optical principles and can therefore pinpoint the location of a threat before it has a chance to act.

So this system is ideal for border and perimeter security as well as VIP protection details.

Name

Parameter

Detection distance

Under the typical meteorological conditions of visibility 10km, ambient temperature 25°C, relative humidity 80%, the detection distance of the sniper sight of φ24mm caliber is not less than 1500m;

Night vision distance

In clear weather conditions, the vehicle identification distance is not less than 300m;

Laser power

 2W;

Laser divergence angle

0.3°~2.7°;

Continuous working time

Under the condition of 25, after one charge, the continuous working time is not less than 1.5 hours;

Dimension

217mm(L)×165mm(W)×90mm(H);

Weight

2.1kg;

Operating temperature

-20℃~+50℃;

Storage temperature

-30℃~+60℃.
