Comparison
|
MH6100B
|
MH675
|
Conclusion
|
|
Detector type
|
Uncooled Microbolometer
|
Uncooled Microbolometer
|
|
|
Detector Resolution
|
640*480px,17um
|
640*480px,17um
|
|
|
NETD
|
<80mk
|
<60mk@300k(F1.0)
|
6100B is better
|
|
Spectral Range
|
8-14um
|
8-14um
|
|
|
Pixel Pitch
|
17um
|
17um
|
|
|
Frame rate
|
50Hz
|
50Hz
|
|
|
Lens System
|
|
Focal Length
|
100mm/F1.2
|
75mm/F1.0
|
6100B is better(bigger lens, farther horizon)
|
|
FOV
|
6.2°x 4.7°
|
8.3°x 6.2°(HxV)
|
6100B is better(smaller FOV, farther horizon )
|
|
Focus
|
8m~infinity
|
Motorized(automatic)focusing
|
|
|
Brightness/contrast
|
Automatically/Manually
|
Automatically/Manually
|
|
|
Image Processing
|
|
Display
|
800x600 OLED
|
800x600 OLED
|
|
|
Polarity
|
White hot/Black hot/
Multiple color modes
|
White hot/Black hot/
Multiple color modes
|
|
|
Digital Zoom
|
2X,4X
|
2X,4X
|
|
|
Video Format
|
MPEG4
|
MPEG4
|
|
|
Record storage
and output
|
Record Format 640*480;Built-in 16G memory card
|
Record Format 640*480;Built-in 16G memory card
|
|
|
Interface
|
Video Output,USD2.0
|
Analog:BNC Digital:USB2.0
|
|
|
Installation Interface
|
1/4’ Standard tripod
interface
|
1/4’ Standard tripod
interface
|
|
|
Battery type
|
26650 Rechargeable
Battery3.7V@5000mAH
|
26650 Rechargeable
Battery
|
|
|
Battery Life
|
Continuous Working
Time after Charging>6hours
|
Continuous Working
Time after Charging≥6hours
|
|
|
Power Consumption
|
<3.0W
|
<3.0W(observation operating)
|
|
|
Detection Range
|
Man:3000m Vehicle:4000m
|
Man:2000m Vehicle:3500m
|
6100B farther detection
|
|
Recognition Range
|
Man:1500m Vehicle:2500m
|
Man:700m Vehicle:1500m
|
6100B farther recognition
|
|
Working temperature
|
-30℃~60℃
|
-30℃~60℃
|
|
|
Storage temperature
|
-40℃~70℃
|
-40℃~70℃
|
|
|
Protection
|
IP66
|
IP66
|
|
|
Humidity
|
5%-95%
|
5%-95%
|
|
|
Weight
|
<1.3kg(including batteries)
|
1.089kg(excluding batteries)
|
|
|
Dimensions
|
22*18*7cm
|
22*17*9cm
|
|
