| Normal FOV is 40,MH-NVYN night vision monocular with FOV 50° |
Engineer Manager Name: Jacky
WhatsApp/ Wechat: 0086-187 9245 6795
Email: mh_elec@126.com or jacky@mh-elec.com
https://youtube.com/shorts/ewh1ANT1w-c
PVS14,MH-NVYN is portable and multi -functional night vision monocular,adopt Generation3 image intensifier tube, with high resolution, small in size, light in weight. Magnification can be changed by replacing different objective lens.This device guarantees quality image for surveillance at night. Normal PVS-14 is only FOV 40° ,MH-NVYN PVS-14 with higher Fov 50°
|
MH-NVYN
|
|
Magnification
|
1x
|
|
Field of view, deg
|
50°
|
|
Lens system
|
26.8mm F/1.2
|
|
Focus range, m
|
0.25m to infinity
|
|
Diopter adjustment, D
|
0
|
|
Eye relief distance, mm
|
14
|
|
Power supply
|
1AA batteries 1.5v/1 CR 123 batteries
|
|
Battery life, hour
|
AA-up to 40,CR123-up to 80
|
|
Dimension, mm
|
115x62x42
|
|
Weight, g
|
370
|
|
GEN II+ IMAGE INTENSIFIER TUBES
|
|
Classification
|
OMNI II+
|
|
Photocathode type
|
18mm S-25+
|
|
Photocathode sensitivity,μA/lm
|
600-900
|
|
Resolution , lp/mm
|
57-70
|
|
Luminous gain, fl/fcd
|
19000-30000
|
|
Signal-to-noise
|
20:1 or better
|
|
Keep time, year
|
10
|
|
Tube reliability standard, hour
|
10000
|
|
EFFECTIVE DISTANCE
|
|
Detection range, m
|
220-250
|
|
Recognition range, m
|
145-180
|
|
ENVIRONMENTAL DATA
|
|
Operating temperature, ℃
|
-32℃ to +50℃
|
|
Storage temperature , ℃
|
-35℃ to +55℃
|
|
Immersion, hour
|
1 meter for 0.5(optional）
|
|
Humidity, ％
|
up to 98%
|
