| Performance parameters
|
01
|
02
|
| Sensitivity
|
2856K Light sensitivity
μA/lm
|
≥1600
|
≥1600
|
| 880 Radiated sensitivitymA/W
|
≥90
|
≥90
|
| Minimum working illumination
|
10-5lx
|
10-5lx
|
| Dark Current
|
≤100e-/s/pix
|
≤100e-/s/pix
|
| Effective pixels
|
1280×1024
|
2048×2048
|
| Pixel size
|
9.76μm×9.76μm
|
11μm×11μm
|
| Brightness non-uniformity (@2856K）
|
≤15%
|
≤15%
|
| Working life (hours)
|
≥1000
|
≥1000
|
| Output frame rate
|
60fps
|
30fps
|
| Operating voltage (V）
|
5V/12V
|
5V/12V
|
| Power consumption
|
≤2W
|
≤2W
|
| Weight(g）
|
≤90
|
≤90
|
| Spectral response range
|
Day mode: 900nm~ 1100nm Night Mode:400nm~900nm
|
| Small high voltage power supply
|
DC high voltage power supply or automatic gated power supply
|
| Image output port
|
Camera Link, USB(customizable)
|
