Specification

• Array format : 1280 × 1024
• Pixel pitch : 10㎛
• Detector type : InSb (Indium Antimonide)
• Wavelength band : 3~5 ㎛ (MWIR)
• NETD : ≤ 25mK
• Operability : ≥ 99.5% (Typ. ≥ 99.9%)
• Channels : 4 or 8
• Readout mode : IWR(Integration While Read)
• Cooldown time : < 8 min
• Environmental condition : MIL-STD-810

Applications

• Thermal Imaging System
• Thermal Observation Device(Day and Night)
• Long Range Surveillance System
• Reconnaissance
