Optical Parameter

Focus/Focal length

4.5 mm

F/#

1.2

Spectral range

8～12μm

Average transmittance(8～12µm)

≥97%(AR)

Detector resolution

384´288 17μm

Back intercept

6.9mm

Field of view (FOV)

90°´73.2°

2.Mechanical parameters

Type of focus adjustment

Prime lens lens

Focus range

0.3m ～∞

Weight

Dimensions

Φ20´12mm

Back working distance

6.4 mm

3.Environment

Operating temperature

-40℃～+70℃

Storage temperature

-40℃～+80℃

Protection class

IP65(First shot of the lens)
