| Dual Sensor Object GPS Coordinate Resolving and Laser Rangefinder Series |
An advanced location resolving algorithm is used to accurately analyze the GPS location of the object, calculate the distance of the object, and superimposed on the display. Laser rangefinder gimbal cameras have a great auxiliary role in the law enforcement , firefighting etc.
Q10TIRM
Dual-sensor Object GPS Coordinate Resolving and
LRF Gimbal Camera
|
Imager sensor
|
1/3" Panasonic CMOS Sensor
|
|
Lens
|
10x optical zoom, F=5.1mm~51mm
|
|
Total pixel
|
2.48M
|
|
Thermal imager
|
640*480, 25mm lens, 25Hz
|
|
Laser range
|
5 ~ 3000 meters
|
|
Object Tracking
|
√
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / IP / SDI
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
716g
|
|
Dimension
|
109.2*128.1*170.1mm
|
Z10TIRM
Dual-sensor Object GPS Coordinate Resolving and
LRF Gimbal Camera
|
Imager sensor
|
1/3" CMOS
|
|
Lens
|
10x optical zoom, F=3.2~33.6mm
|
|
Total pixel
|
4.08MP
|
|
Thermal imager
|
640*480, 19mm lens, 25Hz
|
|
Laser range
|
5 ~ 1500 meters
|
|
Object Tracking
|
√
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / IP/ SDI / DJI Skyport
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
590g / 550g (DJI Version)
|
|
Dimension
|
110.5*128*155.5mm
|
Z30TM
30x Object GPS Coordinate Resolving and LRF
Gimbal Camera
|
Imager sensor
|
SONY 1/2.8" “Exmor R” CMOS
|
|
Lens
|
30x optical zoom, F=4.3~129mm
|
|
Total pixel
|
2.13MP
|
|
Laser range
|
5 ~ 1500 meters
|
|
Object Tracking
|
√
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / IP/ SDI / DJI Skyport
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
732g / 682g (DJI Version)
|
|
Dimension
|
135.5*135*120mm
|
Q30TIRM
30x Object GPS Coordinate Resolving and LRF
Gimbal Camera
|
Imager sensor
|
SONY 1/2.8" “Exmor R” CMOS
|
|
Lens
|
30x optical zoom, F=4.3~129mm
|
|
Total pixel
|
2.13MP
|
|
Thermal imager
|
640*480, 25mm lens, 25Hz
|
|
Laser range
|
5 ~ 1500 meters
|
|
Object Tracking
|
√
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / IP/ SDI
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
1280g
|
|
Dimension
|
157*136*172mm
|
Q30TIRM pro
30x Object GPS Coordinate Resolving and
LRF Gimbal Camera
|
Imager sensor
|
SONY 1/2.8" “Exmor R” CMOS
|
|
Lens
|
30x optical zoom, F=4.3~129mm
|
|
Total pixel
|
2.13MP
|
|
Thermal imager
|
640*480, 25mm lens, 25Hz
|
|
Laser range
|
5 ~ 3000 meters
|
|
Object Tracking
|
√
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / IP/ SDI
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
1110g
|
|
Dimension
|
130.6*165.1*203.2mm
|
QIR19
|
Thermal lens size
|
19mm
|
|
Detector pixel
|
640*480
|
|
Pixel size
|
17μm
|
|
Object tracking
|
None
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / AV
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
440g
|
|
Dimension
|
105*91*98mm
|
ZIR25T
|
Thermal lens size
|
25mm
|
|
Detector pixel
|
640*480
|
|
Pixel size
|
17μm
|
|
Object tracking
|
√
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / IP / SDI
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
650g
|
|
Dimension
|
86mm*120mm*116mm
|
|
Thermal lens size
|
35mm
|
|
Detector pixel
|
640*480
|
|
Pixel size
|
17μm
|
|
Object tracking
|
√
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / IP / SDI
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
495g
|
|
Dimension
|
86.2*112*113.3mm
|
ZIR50T
|
Thermal lens size
|
50mm
|
|
Detector pixel
|
640*480
|
|
Pixel size
|
17μm
|
|
Object tracking
|
√
|
|
Working voltage
|
12V
|
|
Output
|
1080p micro HDMI / IP / SDI
|
|
Local storage
|
SD card up to 128G
|
|
N.W.
|
650g
|
|
Dimension
|
100mm*146mm*141mm
|
