| MH-RM Series Gen3 Night Vision Weapon Sight |
Pls click or email to
mh_elec@126.comorjacky@mh-elec.com
|
Specification Gen2+
|
|
Model
|
MH-RM583
|
MH-RM580
|
MH-RM581
|
|
Magnification
|
3x
|
4.4x
|
6x
|
|
Field of view
|
12º
|
9.3º
|
6.8º
|
|
Lens system
|
80mm F
/1.6
|
110mmF/
1.5
|
150mm F/
2.0
|
|
Focus range
|
10m to infinity
|
10m to infinity
|
10mm to infinity
|
|
Eye relief distance
|
45mm
|
|
Diopter setting,D
|
+3,-4
|
|
Overall dimensions
|
269
x99x87mm
|
294
x89x81mm
|
303
x85x84mm
|
|
Weight
|
1120g
|
1300g
|
1500g
|
|
Power supply
|
1CR123 batteries,3V
|
|
Estimated battery life
|
up to 60 hours
|
|
Image Intensifier Tubes
|
|
Classification
|
OMNIII
|
|
Photocathode type
|
18mm S-25
|
|
Photocathode sensitivity
|
≥550μA/lm
|
|
Resolution
|
48-58 lp/mm
|
|
Luminous gain
|
19000-25000fl/fcd
|
|
Signal-to-noise ratio
|
20:1 or better
|
|
FOM
|
≥1150
|
|
Tube reliability standard
|
10000 hours
|
|
Keep time
|
10 years
|
|
Warranty
|
Oneyear
|
|
Effective Distance
|
|
Detection range
|
200-350m
|
|
Recognition range
|
180-220m
|
|
5mW IR illuminator
|
up to 100m
|
|
Environment Data
|
|
Operating temperature
|
-40℃to+50℃
|
|
Storage temperature
|
-30℃to+50℃
|
