Product Introduction

Large aperture continuous zoom MWIR thermal imager is composed of large aperture continuous zoom lens and ultra-high sensitivity detection module. The super large aperture continuous zoom lens has 10x magnification, which can be used for long-distance target observation and large field of view search; the detection module adopts intelligent image processing algorithms such as adaptive multi background nonuniformity automatic correction technology, image noise filtering, image enhancement, automatic dimming, etc., to ensure high sensitivity and sharp video images. Adopt anti vibration and shock, high and low temperature resistance, sealing treatment and other design means to ensure high reliability and high sealing performance of products. It can be used in photoelectric theodolite, photoelectric turret and other platforms, and can be customized for wide spectral range (3.7 μ m ~ 4.8 μ m) and high frame rate (≥ 100Hz).

Product features

· It is the first large caliber continuous zoom lens in China, with a maximum aperture of φ 314mm；

· The optical axis is stable, less than 2 pixels；

· High sealing performance, up to IP66；

· Adaptive nonuniformity correction technology

·  Intelligent image processing algorithms such as image noise filtering, image enhancement, automatic dimming, etc

· The working temperature range, vibration shock and other environmental adaptability meet the requirements of national military standards

· Spectral response curve of detector
